Electrolux green&clean 520519 Hood-Type XL Πλυντήριο 9,9kW, Τριφασικό Διπλού Τοιχώματος με Ατμοσφαιρικό Boiler, Δοσομετρητές Απορρυπαντικού & Λαμπρυντικού και Αντλία Αποχέτευσης, 60r/h

Product Features

Main Features

• Field convertible from straight to corner operation.
• Green light of "WASH SAFE CONTROL" confirms that items have been rinsed properly.
• Maximum capacity per hour of 60 racks.
• Equipped with specific stainless steel rack designed for perfect washing result on trays, boxes and containers.
• The unit has pre-arranged wiring hardness for easy adapt the user interface on left or right position.
• Pre-arranged to be connected using RS485 cable for on-site HACCP implementation and to an external gateway by means of the modbus protocol.
• Unique temperature interlock guarantees required temperatures in both the wash and final rinse in case of emergency cold water feeding.
• Slanted wash arms to avoid detergent-filled wash water dropping on clean dishes after the rinsing phase, thus guaranteeing ideal washing results.
• Cycle may be interrupted at any time by lifting the hood.
• Automatic self-cleaning cycle and self-draining vertical wash pump and boiler to avoid bacteria proliferation.
• State-of-the-art electronic controls with built-in programming, self-diagnostics for serviceability and automatic interior self-cleaning cycle.
• Boiler power setting from control panel to facilitate technician`s operation when reducing total installed power, thus avoiding the need of machine opening.
• Built-in rinse aid and detergent dispenser with automatic initial and continuous cycle loading for perfect result while minimizing service and maintenance needs.
• Three phase electrical connection, convertible to single phase on-site.
• IP25 protection against water jets, solid objects and small animals (larger than 6 mm).
• Built-in atmospheric boiler sized to raise incoming water to a minimum of minimum 84°C for sanitizing rinse. No external booster is required. Constant temperature of 84°C throughout the rinsing cycle regardless of the network`s water pressure. • 60/90 seconds cycles.
• NSF/ANSI 3 and DIN 10512 compliant.

Construction

• Incorporated drain pump to control water level in wash tank draining.
• Heavy duty Stainless steel construction. Internal cavity as well as exterior panels are in 304 series Stainless steel.
• Prearranged for IoT via on-board communication port. Real-time data transfer of machine status, temperature, alarms, washing cycles performed, cleaning and sanitizing cycles and main diagnostic parameters.
• Pressed tank in front position to facilitate cleaning.
• Specially designed Stainless steel wash/rinse arms and nozzles provide superior cleaning action.
• Revolving interchangeable Stainless steel wash/rinse arms above and below the rack, screw out for simple clean up.
• Element protection from dry fire and low water.
• Double skin hood supported by 4 springs to ensure smooth movement and guarantee operator safety.
• Unit to include drain, detergent and rinse aid dispenser pumps.

Sustainability

• The machine can be connected to cold water.
• Requires only 2.5 liters of water per washing cycle thus ensuring low energy, water, detergent and rinse aid consumption.
